Grizzly Industrial G0946 6 in. Benchtop Jointer with Spiral-Type Cutterhead
The best valued 6 in. benchtop jointer on the market. The G0946 6 in. Benchtop Jointer features a spiral-type cutterhead for smoother finishes, quieter operation, and less maintenance compared with straight-knife cutterheads. The 12 high-speed steel (HSS) inserts sit square to the axis of the cutterhead, with the cutting edges perpendicular to the workpiece. HSS has been heat treated for hardness and wear resistance, which keeps a sharp edge longer than other carbon steels. Each 2-sided insert can each be rotated once to expose a new sharp edge. The 4-sided T32739 Replacement Carbide Inserts are available and sold in packs of ten. The overall size of the inserts making contact with the lumber reduces noise due to a smaller pattern of air being pushed by the cutterhead. The sawdust created by this machine is then finer which is less likely to create clogged dust lines. Compact in size, the G0946 has a small footprint making it easy to move from job sites and stores easily when you want it out of the way. Benchtop models have a bad reputation for being underpowered. The 1-1/2 HP motor is bigger than traditional 1 HP motor options from other brands.
- Spiral-type cutterhead with twelve indexable HSS inserts
- Cast aluminum infeed and outfeed tables
- Infeed table height adjustment lock
- Built-in dust collection system with 2-1/2 in. dust port
- 2 push blocks included
Dimensions
| Product Depth (in.) | 17.5 in | Product Height (in.) | 13.5 in |
| Product Width (in.) | 30 in | Work Table Length (in.) | 30 in |
| Work Table Width (in.) | 6.25 in |
Details
| Amperage (A) | 10 A | Bench & Stationary Tool Type | Jointer |
| Color Family | Multi-Colored | Condition | New |
| Cutterhead Type | Spiral | Horsepower (HP) | 1.5 hp |
| Included | No Additional Items Included | Maximum Board Width (In.) | 6 in |
| Maximum Speed (RPM) | 12000 RPM | Portability | Bench |
| Power Tool Features | Dust Collection | Product Weight (lb.) | 43 lb |
| Tools Product Type | Power Tool | | |
